Introduction

Upheaval buckling refers to the phenomenon that occurs when trenched and buried pipelines are subjected to axial compression forces as a result of high temperature and pressure. The pipeline experiences a large vertical displacement and push up through the soil cover, leaving the pipeline exposes to impact from anchors or trawlboards. Excessive bending is another failure mode.

Upheaval buckling assessment usually consists of finite element analysis on control cases to determine the approximate amount of 'cover' required on a pipeline.



Notable Projects

Project Name
Project Number
Notes
BAOBAB
Notable due to the Pipe in Pipe nature
Greater Plutonio
Deep Water, using SAFEBUCK
Qatar Gas
KW

Large Diameter Pipe
Shallow Water
Snake Lay Solution



Other Projects

Project Name
Project Number Notes
EPC2B
KW 0728
Controlled Buckles on Existing Pipeline Crossings
Algeria Pipeline
KW 1071
Onshore
Deep Panuke




Codes & Standards

Company
Title
Doc Number / Date
SAFEBUCK JIP
Safe Design of Pipelines with Lateral Buckling - Design Guideline
DNV
Global Buckling of Submarine Pipelines
DNV-RP-F110
DNV
Submarine Pipeline Systems
(Strain Based Limit State)
DNV-OS-F101



Course Notes

Author
Title
Notes
C. Sicilia
Lateral Buckling Assessment and Mitigation Design
Trevor Gee
IBC
Pipeline Course



Books

Author
Title
Chapter
Mikael Braestrup
Design and Installation of Marine Pipelines
6.5



Papers

Author
Title
Notes
Hobbes, R. E.
In-service Buckling of Heated Pipelines, Journal of transportation Engineering, ASCE, Vol. 110, No.2, March 1984, pp. 175-189
Approximate method for determining propensity for lateral buckling
Taylor, N. and Gan, A. B
Submarine pipeline Buckling – Imperfection Studies, Jour. Of Thin-walled Structures, Vol. 4, 1986, pp 295-323
A developed version of ‘Hobbs’, including the effects of initial OOS



Prepared Calculations

Title / Software
Description
Owner / Athor
Hobbs / Excel
Predicts the onset of buckling
KAJW / CSG



Related Subjects

Expansion

Lateral Buckling

Upheaval Buckling

Return

After installation a survey is usually conducted to determine the vertical profile of the pipeline and the amount of soil/rock cover. This information is used to determine if further cover is required to ensure that the pipeline will not be susceptible to upheaval buckling.
